FEMALE HEAD
25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
Pedicle : Scape
The head is Hypognathous (Meaning the mouth parts are located ventrally for eating leaves)
Maxillary Palps
Labial Palps
Mandibile
Flagellomia segment
Home
EXTATOSOMA TIARATUM - ADULT FEMALE
Body Parts
Antennae & Head
Abdomen
Legs
EXTATOSOMA TIARATUM - ADULT MALE
Body Parts
Antennae & Head
Adult Wings
Abdomen & Legs
ACHRIOPTERA MANGA - ADULT FEMALE
Body Parts
Antennae & Head
Adult Wings
Abdomen & Mesanotum
Legs
Extatosoma tiaratum adult female antenna & head
ANTENNAE
X2 Compound eyes which consists of tiny tubes called Ommatidae (Light sensing cells)
The antennae normally has 21 segments. The Scape is mounted into a socket that allows the insect to move the antennae. The 2nd segment is called the Pedicle which detects motion. This also contains the Johnson's organ. The remaining segments of the antennae are called Flagellomias. The antennae are covered with small hairs which are called Sensory Setae. This helps the insect locate it's surroundings.
At the top of the female head (Conical Occiput) a cluster of thorny spines are for protection
X2 Compound eyes
X2 Filiform antennae
X2 Compound eyes
3 small simple eyes are located on top of the head just behind the antenna. These are called Ocelli and used as detectors and enable the insect to make directional corrections during flight. This mostly applies to the male.
